Product parameters
1. Model example: NRV-VS-F1 30/40/50/63/75/90/110
2. Transmission ratio range: 5~100 (common models)
3. Input power: 0.12kW~18.5kW
4. Output torque: 15N·m~2500N·m
5. Input speed: ≤1800r/min (recommended value)
6. Installation form: Flange type (F1 type special flange interface, suitable for B5/B14 standard motor)
7. Efficiency: 75%~92% (dynamically adjusted according to transmission ratio and load)
8. Weight: 2.5kg~150kg (increases with model)
9. Protection level: IP66 (enhanced dust and water resistance)
10. Operating temperature: -25℃~+100℃ (short-term tolerance temperature can reach 120℃)
NRV-VS-F1 worm gear reducer is a precision reduction device based on worm gear transmission, designed for high-precision and high-reliability industrial scenarios.
Its core features include:
- Worm gear structure: The worm adopts 45# steel high-frequency quenching process, and the worm wheel uses tin bronze material to achieve a balance between high strength and wear resistance.
- Special flange interface (F1 type): Optimize flange size and bolt hole position, adapt to servo motors, stepper motors and general asynchronous motors, and reduce the need for installation adapters.
- Modular expansion: Supports multi-stage series or parallel configuration, and flexibly expands transmission ratio and output torque.
- Lubrication design: Built-in long-lasting grease (optional food-grade lubricant), suitable for clean environments.
Industrial automation: Robotic arm joint drive, automated assembly line, precision positioning platform.
- New energy equipment: Photovoltaic tracking bracket adjustment, wind power generation variable pitch system.
- Medical equipment: CT machine rotation mechanism, surgical robot transmission module.
- Food processing: Aseptic filling machine, mixing tank drive, packaging machinery power transmission.
- Railway transportation: Platform safety door drive, carriage ventilation system adjustment.
1. High-precision transmission
- The meshing clearance of the worm gear is adjustable (≤0.05mm), suitable for precision positioning control.
2. Enhanced sealing performance
- Double lip oil seal + labyrinth seal structure to prevent grease leakage and external contaminants from intruding.
3. High temperature resistant design
- The housing is made of ADC12 aluminum alloy die-casting, with excellent heat dissipation performance and supports short-term high-temperature operation.
4. Low backlash and high rigidity
- The output shaft is quenched and tempered, and the radial load capacity is increased by 20%, which is suitable for heavy-load swing scenarios.
5. Intelligent compatibility
- Optional encoder interface or brake module can be used to meet the closed-loop control requirements of the servo system.
6. Green and energy-saving
- Optimized tooth design reduces friction loss, and the comprehensive energy efficiency ratio is increased to more than 90%.
7. Safety redundancy
- Double self-locking function (mechanical self-locking + optional electromagnetic brake) to ensure the safe parking of vertical loads.
The technical process of worm gear reducer integrates the three core advantages of high-strength materials, precision processing, and modular design. Through carburizing and quenching, CNC gear grinding, double seal structure and other innovative processes, it achieves a balance between high precision, high reliability and environmental adaptability. Its process cost is relatively high, but it is suitable for industrial scenarios with strict performance requirements, such as automation, new energy and medical equipment.
For exclusive deals and latest offers, sign up by entering your email address below.
1. What is an NRV Worm Gear Reducer? The NRV worm gear speed reducer is a widely used mechanical device in industrial applications. It belongs to the family of worm gear reducers and is designed to reduce the rotational speed of an input shaft while increasing the torque output...
View MoreIn the stage of modern industrial precision transmission, Worm Gear Machine Screw Lift has become the core "transmission hub" of many industries with its unique structural design and excellent performance. From the production line of manufacturing industry to the lifting platform...
View MoreWhat is worm gear speed reducer A worm gear speed reducer is a reduction transmission device composed of a worm wheel and a worm. Its working principle is based on the meshing transmission of the worm wheel and the worm. The rotation of the worm drives the worm wheel to rotate, t...
View MoreHangzhou Yinhang Reduction Gears Co., Ltd. is located in the industrial and commercial center of China, close to the Shanghai-Hangzhou-Ningbo Expressway and Xiaoshan International Airport, with superior geographical location, technical resources and cultural environment. The company's products are sold well throughout the country and exported to Europe, America, the Middle East, South Asia and Australia. After years of rapid development, the company has become a backbone enterprise of Hangzhou's "Hometown of Reducers", specializing in the research and development, production and sales of NRV-VS-F1 worm gear speed reducers.
1. Core technical advantages of NRV-VS-F1 worm gear reducer
This product uses high-quality aluminum alloy shell, which has the characteristics of beautiful, lightweight, and never rusting. It is widely used in light industry, chemical industry, food, packaging, glass machinery, ceramics, pharmaceuticals and other industries, as well as various production automation lines, conveyor lines, assembly lines, etc. that require speed regulation.
2. Transmission efficiency optimization design
Precise meshing of worm and gear: high-precision grinding technology is used to ensure close meshing between the worm and the worm wheel, reduce friction loss, and improve transmission efficiency (usually up to 90% or more).
Low backlash design: optimize the matching of gear pairs, reduce the return clearance, and is suitable for automation equipment with high-precision positioning requirements.
Lubrication technology: high-performance grease or oil bath lubrication is used to reduce operating temperature rise and extend service life.
3. Self-locking characteristics and their applications
One-way self-locking function: the special helix angle design of the worm and gear enables the worm to drive the worm wheel, but the worm wheel cannot reversely drive the worm, which is suitable for anti-reversal scenarios (such as elevators, conveyor belts, etc.).
Safe and reliable: in the event of power failure or emergency shutdown, the self-locking function can prevent the load from sliding down and improve the safety of the equipment.
Applicable industries: food packaging machinery, automated assembly lines, glass production lines, etc., where precise positioning + anti-retraction is required.
4. Industry competitiveness
As a Custom NRV-VS-F1 Worm Gear Speed Reducer Manufacturers and China NRV-VS-F1 Worm Gear Speed Reducer Suppliers, Hangzhou Yinhang Reduction Gears Co., Ltd.'s products are widely recognized in domestic and foreign markets due to their advantages such as lightweight, corrosion resistance, and low noise. They are especially suitable for industries with high hygiene requirements such as food grade and medical grade.
Typical Application and Selection Guide of NRV-VS-F1 Series Worm Gear Reducers in Industrial Automation
Hangzhou Yinhang Reduction Gears Co., Ltd. is located in the industrial and commercial center of China, close to Shanghai-Hangzhou-Ningbo Expressway and Xiaoshan International Airport, with superior geographical location, technical resources and cultural environment. The company's products are sold well throughout the country and exported to Europe, America, the Middle East, South Asia and Australia. After years of steady development, it has become a backbone enterprise in Hangzhou's "Hometown of Reducers", specializing in the customized production and supply of NRV-VS-F1 worm gear reducers.
This series of products uses high-quality aluminum alloy shells, with the advantages of beautiful, lightweight, and never rusting. It is widely used in light industry, chemical industry, food, packaging, glass machinery, ceramics, pharmaceuticals and other industries, as well as various production automation lines, conveyor lines, assembly lines, etc. that require speed regulation, and is well received by customers.
1. Typical applications of NRV-VS-F1 worm gear reducer
Food packaging machinery
Applicable to filling machines, sealing machines, labeling machines, etc. The aluminum alloy shell meets food-grade hygiene requirements, is corrosion-resistant and easy to clean.
Automated production line
Provide stable speed regulation in assembly lines, conveyor belts, and sorting systems to ensure precise transmission and low-noise operation.
Glass and ceramic equipment
Used in precision machinery such as cutting and edge grinding, the self-locking characteristics of the worm gear prevent load reversal and improve safety.
Pharmaceutical and chemical equipment
Corrosion-resistant materials are suitable for humid or chemical environments, such as mixers, filling equipment, etc.
Light logistics system
Achieve efficient power transmission in sorting machines and lifting platforms, and lightweight design reduces equipment load.
2. Key factors for selection
Load and torque requirements
Select the appropriate model according to the torque (N·m) required by the equipment to avoid overload or power waste.
Reduction ratio range
NRV-VS-F1 series provides a variety of reduction ratios (such as 5:1 to 100:1), which need to match the motor speed and output requirements.
Installation method
Support flange (NRV) or vertical (NRV-VS) installation to adapt to different space layouts.
Environmental adaptability
The aluminum alloy housing is suitable for humid and dusty environments, and the protection level (such as IP65) can be customized for special working conditions.
Energy efficiency and maintenance
The worm gear transmission efficiency is about 70%~90%, and regular lubrication is required for long-term operation (food-grade grease is recommended).
3. Customization advantages of Hangzhou Yinhang
Flexible design: supports customization of non-standard shaft diameters and flange sizes to meet the integration needs of special equipment.
Global certification: complies with ISO 9001 standards, and some models have passed CE certification to ensure export compliance.
Quick response: Relying on the Yangtze River Delta supply chain, providing one-stop service from selection to after-sales.
